M4/8.SFD Screw Clamp Terminal Block. For 5 x 20 and 5 x 25 fuses, with blown fuse indicator, Grey. Protect your circuits with 5×20 and 5×25 fuse terminal blocks (fuse not supplied with terminal blocks), Quickly identify the defective circuit thanks to the blown fuse indicator.
Specifications
| Brand Name | TE Connectivity | Item Name | Terminal Block |
| Voltage Rating | 400 V | Amperage Rating | 6.3 A |
| Number of Poles | 1 | Conductor Size | 12 AWG |
| Mounting Type | DIN-Rail | Series | SNA Series |
| Wire Strip Length | 9.5 mm | Spacing | 8 |
| Torque Rating | 0.8 N-m | Connection Type | Screw Clamp |
| Temperature Rating | -55 to 110 °C | Block Material | Polyamide |
| Color | Gray | Dimensions | 41 mm L x 8 mm W x 56.5 mm H |
| For Use With | 5 x 20 and 5 x 25 Fuses | Standards | UL 94V-0, RoHS EU Directive 2002/95/EC, IEC 60715, IEC 60947-1 |
