Plug-in Relay, Basic 8-pin Octal Base DPDT, 10A, 120VAC Uses Socket 3TX7144-1E2 or 3TX7144-4E2
Specifications
| Brand Name | Siemens | Sub Brand | Sirius |
| Item Name | General-Purpose Relay | Voltage Rating | 300 V |
| Coil Rating | 120 VAC | Contact Configuration | DPDT |
| Amperage Rating | 10 A | Contact Material | Silver Alloy |
| Degree of Protection | IP40 | Temperature Rating | -40 to 85 °C |
| Standards | RoHS Compliant, UL Listed | UPC | 754554970141 |
