Sealey Inverter Welder 140A 230V
Ultra-compact and lightweight unit weighing approximately 4kg.
Portability allows the welder to be taken to the job at hand, ideal for mobile technicians.
Unit can ARC/MMA weld a variety of rods including rutile, basic and stainless from Ø1.6mm up to Ø3.2mm.
Features LED display, with thermal cut-out protection, anti-stick, arc force and hot start functions.
Supplied with 1.6m 16mm² cable with electrode holder and a 1.4m 16mm² earth clamp and cable, both with 10-25 dinse connectors.
Forced air cooling system.
Specification:
- Model No MINIMW140i
- Brand: Sealey
- Nett Weight: 3.9Kg
- Welding Current: 20-140A
- Duty Cycle: 100% @ 108A, 60% @ 140A
- Electrode Capacity: Ø1.6-3.2mm
- Absorbed Power: 4.2Kw
- Supply: 230V-16A**Note: To achieve maximum power a 16A supply may be required.
- Protection: IP21S
- Weight: 3.9Kg
({IF[“Supply: 230V-16A**Note: To achieve maximum power a 16A supply may be required.”!=]})
({ENDIF})
Product Guarantee: 1 Year
Catalogue Page: Page 994
Downloadable Files:
- Instructions: View Here
- Parts Diagram: View Here
