Features & Benefits:
- Toolless Wheel Change And 3 Position Guide Plate Adjustment
- 5″ (Round) Cutting Capacity
- AC Only
- Mitres 45° Left
- Toolless wheel change feature enables fast and easy blade changes without the need for additional tools
- Toolless 3 position guide plate adjustment for fast and accurate angle setting
- Quick release vise enables fast clamping of materials
- Pin lock secures saw head in downward position for safe transportation and storage
- Lock off button prevents accidental start up
- Enlarged spark guard and holder for increased spark collection
- Large top carrying handle for easy transportation
Specifications:
- Blade Diameter — 14″ (355 mm)
- Arbor — 1″ (25.4 mm)
- No Load Speed — 3,800 RPM
- Cutting Capacity:
- 45 Degrees– 5″ (127 mm)
- 90 Degrees– 5″ (127 mm)
- AMPS (120V) — 15.0 A
- Overall Length — 20-7/8″ (530 mm)
- Net Weight — 37.9 lbs (17.2 kg)
Standard Equipment:
14″ Abrasive Wheel (1 Ea. B-23204-5), Vise (135708-8)
