Features & Benefits:
- Incorporates Makita’s Deep And eXact Cutting Technology (DXT) Up To 15″ Cuts In 2x Material, 8″ Nested Crown Moulding and 6-3/4″ Vertical Baseboard
- NEW Close To Wall “Zero Clearance” Design!
- Rail forward design enables saw to be placed against wall to maximize effective workspace
- Integrated guide fence and lower fence increases rigidity and support of materials
- Front bevel knob enables easy adjustment without reaching for operator convenience and precise setting of bevel angle
- Constant speed control maintains constant speed under heavy load
- Soft start feature gradually increases speed to eliminate start up shock
- Electric brake stops blade quickly after trigger is released for increased operator safety
- Bevel capacity of 48o left or right with positive stops at 0o, 22.5o, 33.9o, 45o & 48o
- Mitre capacity of 60o left or right with positive stops at 0o, 15o, 22.5o, 31.6o, 45o & 60o
- Large mitre table ideal for use with wide materials
- Easy to operate mitre angle lock with free spin releasing lever and locking lever
- Improved dust collection with dual dust collection ports
- Horizontal handle design with 2 stage safety switch for increased operator safety
- Ergonomic horizontal soft rubber grip design for vibration absorption and comfortable operation
Specifications:
- Blade Diameter — 12″ (305 mm)
- Arbor — 1″ (25.4 mm)
- No Load Speed — 3,200 RPM
- AMPS (120V) –15.0 A
- Vibration Level –2.5 m/s2
- Noise Level –91 dB(A)
- Dimensions (L xW x H) — 35-1/4″ x 26-1/8″ x 28-1/2″ (898 mm x 664 mm x 725 mm)
- Net Weight — 64.6 lbs (29.3 kg)
Standard Equipment:
12″ C.T. Blade 60T (A-93712), Dust Bag (122852-0), Vertical Vise (126617-2), Triangle Rule (762001-3), Holder 90 (327145-2), Hex Wrench 6 (781044-6)
