Features:
- Two-Stage Safety Paddle Switch (AC)
- Active Feedback-sensing Technology (AFT), Mechanical Brake, Soft Start, Anti-Restart
- Active Feedback sensing Technology (AFT) automatically shuts down the tool if there is a sudden drop in rotation speed (e.g. kick-back)
- Soft start feature gradually increases speed to eliminate start up shock
- Constant speed control maintains constant speed under heavy load
- Anti-restart feature prevents tool from operating if it is plugged in when locked in the on position
- Labyrinth construction features a complex series of channels to prevent penetration of dust and debris into the field and armature for maximum operational life
- Motor winding protection features “Zig-Zag” varnish on the armature and hardened powder on the field coils to act as an impenetrable barrier to dust and debris
- Anti-vibration rear handle ideal for improved operator comfort during periods of prolonged use
- Rear handle swivels 180o to adjust to the most comfortable grinding position
- Rotatable gear housing can be positioned at every 90o for optimal positioning
- Transparent cover protects serial number against wear
- Removable 3 position side handle can be mounted on left, right or top side of tool
- Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Specifications:
- Maximum Capacities:Grinding Wheel –9″ (230 mm)Spindle Thread –5/8″ – 11 UNCNo Load Speed –6,600 RPMAMPS (120V) –15.0 AVibration Level — 4.9 m/s²Noise Level — 91 dB(A)Overall Length –20″ (506 mm)Net Weight –13.9 lbs (6.3 kg)
Includes:
- Side Handle (143486-6), Lock Nut Wrench 28 (782412-6), Wheel Cover (141E83-2), Inner Flange (224500-8), Lock Nut 5/8″-45 (224486-6)
