- Safety guard with limit switch protection
- Magnetic line interruption switch needs a restart after a power failure
- Head swivels 180° and is easily raised and lowered
- Head travels up to 14″
- Spindle is equipped with heavy-duty tapered bearings
- Powerful 1.5 HP single phase Motor
- Magnetic line interruption switch and safety guard with limit switch protection
- Complete with forward reverse switch, 1/2″ chuck with key, safety guard and stand
Details:
- DRILLING CAPACITY: 1-1/4″
- MAX. DISTANCE SPINDLE NOSE TO TABLE: 21-1/4″
- SWING: 38-1/2″
- SPINDLE: MT 3
- SPINDLE STROKE: 5-1/4″
- COLUMN DIAMETER: 4-1/2″
- SPEEDS (RPM): 5 (340-3,000)
- TABLE DIMENSIONS: 21-5/8″ x 19-5/8″
- HEAD TRAVEL: 14″
- SIZE OF T-SLOT ON TABLE: 5/8″
- MOTOR: 8.8 Amp.
- VOLTAGE: 220V, 60 Hz, 1 phase
