Operators are all aluminum except for certain movable parts which are stainless steel, all other parts such as screws are either stainless steel or plated steel. Threaded bodies are all 3/4″-14 NPSM thread. Control stations can be grouped into a single assembly thus reducing installation time and cost. Junction boxes may be used to mount operators along with glass lens for viewing internally mounted meters. Additional relays, timers, terminal blocks, or other equipment may also be internally mounted to provide a single centralized control unit.
Specifications
| Brand Name | Killark | Item Name | Pilot Light Operator |
| Type | Long Blank | Voltage Rating | 110 – 120 V |
| Amperage Rating | 25 mA | Wattage | 3 W |
| Lens Color | Green | Dimensions | 5-3/8 in L x 1-35/64 in W x 1-35/64 in H |
| For Use With | B7E, EXB, XJB, DB, SWB, and GCS Series Boxes and B7, Y7 Starter Enclosures | Standards | CSA Certified, UL Listed |
| Application | For Use in Hazardous Locations | UPC | 783936997186 |
