FXSD Series requires no external seals (factory sealed) and are NEMA 3 (raintight) rated. Enclosures are cast copper-free aluminum alloy. Operating shaft is stainless steel. Ground flange joint between bolted cover and box provide required flame path. Pro
Motor running protection when overload heaters are used.
Factory Sealed so no external seals are required.
Type 3 (raintight) rated.
Enclosures are cast copper-free aluminum alloy.
Operating shaft is stainless steel.
Multiple gang assemblies available in combination with pilot lights, pushbuttons and switches on request.
Ground flange joint between bolted cover and box provide required flame path.
Provisions for padlocking switch in either “ON” or ”OFF” position is standard.
N/A
Specifications
Brand Name
Killark
Sub Brand
Killark
Item Name
Manual Motor Starting Switch with Overload Protection
Type
Aluminum manual motor starting switch with overload protection
Coil Voltage
115 – 230 VAC
Control Voltage
230 VAC
Power Rating
1 HP @ 115-230 VAC
Phase
1
HP Rating
1 hp
Number of Poles
1
Actuator Type
Lever
Dimensions
3-11/16 in W x 5-11/32 in D x 6-13/16 in H
Series/Model
FXSD
Material
Aluminum
Enclosure Type
Aluminum enclosure
NEMA Rating
NEMA 3
Standards
UL Listed, CSA Certified, FM Approved
Application
Provides Manual Starting and Stopping of Small AC or DC Motors, Motor Running Protection When Overload Heaters are Used
UPC
783936197371
