The 12/24Vdc 0.5 Amp Positive Logic Output module, IC694MDL732,provides one group of eight outputs with a common power output terminal. This module has positive logic characteristics; it sources current to the loads from the user common or positive power bus. The output device is connected between the negative power bus and the module output. The output characteristics are compatible with a wide range of load devices, such as: motor starters, solenoids, and indicators. Power to operate the field devices must be supplied by the user. Individual numbered LEDs show the ON/OFF status of each output point. There are no fuses on this module. The blue bands on the label show thatMDL732 is a low-voltage module. This module can be installed in any I/O slot in an RX3i system. Module supports insertion into and removal from an RX3i Universal Backplane which is under power.
Specifications
| Brand Name | GE | Sub Brand | PACSystems™ |
| Item Name | Output Module | Type | Discrete, DC Voltage, Positive Logic |
| Voltage Rating | 12/24 VDC | Output | (8) Point |
| Interface | PROFINET, Modbus/TCP, Ethernet Global Data (EGD), Control Memory Exchange (CMX), PROFIBUS DP | Communication Ports | Serial Communications, Modbus/RTU, Modbus/TCP, HART, GENIUS, DNP3 Serial/TCP, IEC-61850, IEC-104, Reflective Memory, PROFIBUS/Master, CANOpen |
| Dimensions | 34 mm W x 140 mm D x 145 mm H | Series/Model | RX3i Series |
| Amperage Rating | 0.5 A | Connection | (2) RJ45 and (2) SFP |
| Mounting Type | Panel, Rack | Degree of Protection | IP20 |
| Temperature Rating | 0 – 60 °C | For Use With | PACSystems RX3i Control Systems |
| Standards | ATEX Zone 1, CE Certified, UL HazLoc C1D2, UL Listed | Application | Complex Machine, General Automation, Motion Control and Process Control Applications |
