The 120/240 Vac 2 Amp Isolated Output module, IC694MDL390, provides five isolated output points, each with a separate common. Each output circuit is isolated from the others relative to the AC power source. The commons are not tied together inside the module. The output circuits can be used on different phases of the AC supply or powered from the samesupply.AC Power to operate the loads connected to the outputs must be supplied by the user. This module requires an AC power source, it cannot be used with a DC power source. Outputs are individually fused with a 3 Amp fuse. An RC snubber protects each output against transient electrical noise on the power line. This module provides a high degree of inrush current (greater than 10 times the rated current) so the outputs can control a wide range of inductive and incandescent loads. Individual numbered LEDs show the ON/OFF status of each output point. The red LED (F) turns ON if an output fuse blows. The red bands on the label show that MDL390 is a high-voltage module. This module can be installed in any I/O slot in an RX3i system. It should be configured as an 8-point output module with programs referencing the five least significant bits. Module supports insertion into and removal from an RX3i Universal Backplane which is under power.
Specifications
| Brand Name | GE | Item Name | Output Module |
| Voltage Rating | 120/240 VAC | Input | (5) Point |
| Amperage Rating | 2 A | Frequency Rating | 50/60 Hz |
| Power Consumption | 110 mA |
