Ideally suited for high-inrush fluid pump controls: pool/spa, water processing, emergency, chemical industry, etc. High-capacity, high-withstand voltage relay with no contact chattering for momentary voltage drops up to 50% of rated voltage. UL Class B construction standard. Flame resistant materials (UL94V-0-qualifying) used for all insulation material. Quick-connect, screw, PCB terminals and DIN track mounting available. Conforms to UL, CSA, TUV and meets IEC 950. Safety design with contact gap of 3 mm. RoHS Compliant.
Specifications
| Brand Name | Electrosonic | Item Name | General Purpose Relay |
| Voltage Rating | 0 – 250 VAC at 50/60 Hz | Contact Configuration | DPST |
| Coil Rating | 24 VDC | Connection | Screw |
| Mounting | Upper Bracket | Dimensions | 68.5 mm W x 36.5 mm D x 49 mm H |
| Includes | LED Indication |
