- CS Unitec
- EKF 300.3 comes with 30 degree; Chamfer 0-1/4″
- Bevel; deburr & chamfer edges of steel plate faster and cleaner than angle grinders
- The EKF multi-purpose beveling machine is designed to bevel 30 or 45 weld seams on steel; stainless steel; nonferrous metals; brass and plastics. It can also be used to deburr and chamfer; straighten edges; internal and external radii; and countersink holes from 7/8″ diameter.
- Fine adjustment feature for slight chamfers when deburring for the preparation of weld seams
- Three milling heads30; 45 and radius R2.5are available
- Ideal for the following applications: Moldmaking (straighten edges; internal and external radii and countersink holes from 7/8″ dia.); Boiler and process plant construction (prepare weld seams on heat exchangers); Mechanical engineering (deburr machine parts; chamfer edges to protect against paint peeling and create visible edges); Sheet metal (deburr cut edges)
- Model No.: EKF300 EKF450 EKF452
- Beveling Angle*: 30 45 R 2.5 radius(optional heads)
- Bevel Width (max.)**: 1/4″
- Motor Power: 10 Amp
- Voltage: All machines: 110 V (220 V / 50 Hz also available)
- Cutting Speed: 3000 SFPM
- Dimensions (LxWxH): 12-1/4″ x 5-1/2″ x 11-5/8″
“
