BVA Hydraulics
10 Ton 10 Stroke Single Acting Threaded Cylinder HT1010
FEATURES:
- Ideal for frode pulling machine
- High quality threaded single acting cylinders
- Spring return
- Removable threaded rod adapter allows for the use of a variety of threaded attachments
- Used to attach accessories to rod end and base
- Maximum working pressure: 10;000 psi / 700 bar
SPECIFICATIONS:
| Cylinder Capacity(tons) | 10 |
|---|---|
| Stroke(in) | 9.96 |
| Cylinder Effective Area(in) | 2.24 |
| Internal Pressure at Capacity(psi) | 8;928 |
| Oil Capacity(in) | 22.3 |
| Collapsed Height (in) | 11.46 |
| Extended Height (in) | 17.41 |
| Outside Diameter (in) | 2.26 |
| Rod Diameter (in) | 1.49 |
| Base to Inlet Port (in) | 1.67 |
| Collar | 2.25-14UNC |
| Collar Thread Length (in) | 1.13 |
| Saddle HeightS(in) | 0.94 |
| Weight(lbs) | 10.6 |
“
