FEATURES:- Power circuit (AC): Up to 690V- Control circuit- Alternating current up to 690V AC- Direct current up to 440V DC- Terminal numbering in accordance with EN50005 and EN 50012- Fixing by clipping onto 35mm DIN rail EN50022-35 or by screws- Degree of protection IP20 screws protected against accidental contact in accordance with VDE 0106- Three coil terminals
Specifications
| Brand Name | Emerson | Item Name | IEC Contactor |
| Type | Non-Reversing | Coil Voltage | 24 VDC |
| Power Rating | 16 kW | Phase | 3 |
| Contact Configuration | 1 NO | Number of Poles | 3 |
| Terminal Connection | Screw | Dimensions | 2.15 in W x 3.45 in D x 5.3 in H |
| Mounting Type | DIN Rail/Panel | Series/Model | C-2000 |
| Voltage Rating | 460 V | Amperage Rating | 32 A |
| Frequency Rating | 50/60 Hz | HP Rating | 20 hp |
| Standards | CSA, CE, UL Listed | Application | Electrical Distribution and Control |
| UPC | 425095120967 |
