The MC1C301ATD mini contactor is a dimension optimized 3 pole contactor with 1 NC auxiliary contact and screw terminals. This device is a great solution when high performances are needed but the space is limited. Mini contactors are used in residential buldings, commercial buildings and industrial applications for the control of single or three-phase loads up to 4 kW (AC-3) and 20 A / 690 V (AC-1) or switching of control signals. The product is suitable for wall or rail mounting.
Specifications
| Brand Name | ABB | Sub Brand | GE Industrial Solution |
| Item Name | Contactor | Type | Mini |
| Full Load Current | 6.1 A | Power Rating | 4 kW |
| Contact Configuration | 3 NO, 0 NC | Number of Poles | 3 |
| Terminal Connection | Screw | Dimensions | 45 mm W x 68 mm D x 48 mm H |
| Mounting Type | DIN Rail | Voltage Rating | 690 VAC |
| Amperage Rating | 20 A | Frequency Rating | 50/60 Hz |
| Conductor Size | 18-12 AWG | Degree of Protection | IP20 |
| Temperature Rating | -40 to 70 °C | Standards | RoHS Compliant |
| Application | For Electrical Distribution and Control | UPC | 425095002263 |
