20-Gallon Two Stage Gasoline Air Compressor – AM2-PH09-20M

20-Gallon Two Stage Gasoline Air Compressor – AM2-PH09-20M designed to maximize productivity

This model features a powerful and efficient two stage compressor designed to maximize productivity. The versatility of the 20-gallon air compressor offers extra air storage and comes in stationary or portable models.

Compressor Pump: Splash lubricated · Stainless-steel braided discharge hose · Large canister intake filter · Oil level sight indicator

Frame: Powder coated ASME coded 20-gallon receiver tank · 3/16-inch base plate to reduce vibration · 14-gauge powder coated two-piece belt guard · 13-inch flat-free tires

Components: Regulator and two gauges for tank and outlet pressure · Manual drain valves for proper maintenance · 16 1/2-inch fly wheel · Quality pilot valve unloader

*Equipped with 150-PSI maximum rated regulator

Specifications

• CFM @ 175 PSI*

  17.2

• Displacement/ Engine

  270cc Honda GX270 OHV

• Compressor

  Two Stage, Cast Iron

• Tank Size

  20 gallon

• Engine Idle Control

  Pneumatic
