The horizontal 120-gallon air compressors can be installed in service shops where compressed air is a required utility
Powerful and efficient, they are designed to maximize production.
Compressor Pump: Splash lubricated · Stainless-steel braided discharge hose · Large canister intake filter · Oil lever sight indicator
Motor: Industrial low RPM motor · Magnetic start for thermal overload protection
Frame: Powder coated ASME coded 120-gallon receiver tank · 3/16-inch base plate to reduce vibration · Totally enclosed powder coated belt guard
Components’ safety valves · Tank pressure gauge · Hour meter · Large fly wheel · Tank shut-off valve · Intake filter/silencer · 3 position switch – compressor 1 (lead motor pump), automatic alternating and compressor 2 (lead motor pump)
Other Models Available:ACD-20305-120H 200V, 32.2A, 3 PhaseACD-23305-120H 230V, 27.6A, 3 PhaseACD-46305-120H 460V, 13.8A, 3 Phase
Specifications
-
CFM @ 175
36.0
-
Horsepower/Motor
5.0 HP, 230V, 1Ø, 46.0A
-
Pump RPM
860
-
Compressor
Two Stage, Cast Iron
-
Tank Size
120 gallon
-
Bolt Down (LxW)
34.5 x 23.5 in.
