Features
- Compact, high density, 1U package
- GPIB, LAN, USB and RS485 Interface
- External analog programming interface
- Easy to configure master/slave mode for series & parallel connection of up to 4 units
- Control up to 31 power supplies from one PC synchronized via the RS485 interface
- Application software providing remote control capabilities included
- Programmable voltage and current slew rate allow for “soft starting” of loads
- LabVIEW (TM) drivers available
- 5 V/1 A fixed output for auxiliary output
- AC or DC Output: DC
- Maximum Current: 14.4 A
- Maximum Power: 1440 W
- Maximum Voltage: 100 V
- Number of Outputs: 1
- Ranging: Single
- Warranty: 3 years
